CCS2 AC EV Fast Charger, 3.5kW, 16A, Type 1 Plug, IP67
Key Specifications / Features
Model no.: ACEVC-20240815-03
Hits: 4
As a leading supplier of Type 1 plug EV chargers from China, we offer a top-quality solution with exceptional features. Our charger integrates the CCS2 interface, delivering a reliable 3.5kW output power with a 16A output current. Designed for versatility and durability, it boasts an IP67 rating, ensuring superior protection against dust and water. The 5-meter cable length provides ample flexibility for various charging setups. Operating at 220V, this charger is perfect for efficient and effective electric vehicle charging, making it an ideal choice for both residential and commercial applications.
Request a quote
Tags
Detail Information
CCS2 16A EV Charger, IP67, Type 1 Plug, 5M Cable, 3.5kW
| Product Item: | 16A AC EV Charger |
| Rated Power: | 3.5kW |
| IP Degree: | IP67 |
| Cooling: | Natural Cooling |
| Output Current: | AC |
| Interface Standard: | CCS2 |
| Rated Input Voltage: | 220V±10% |
| Rated Intput Current: | 16A |
| Rated Output Voltage: | 220V±10% |
| Rated Output Current: | 16A |
| Way of Communication: | Plug and Play |
| Length of Charging Plug: | 5M |
| Size(H*W*D): | 206*84*50mm |
| Weight: | ≤3kg |
| Operating Temperature: | -30°C to +50°C |
| Storage Temperature: | -25°C to +50°C |
| Multiple Protection: | With Over Voltage Protection, Under Voltage Protection, Overcurrent Protection, Grounding Protection, Surge Protection, Short Circuit Protection. |
