AC EV Fast Charger, 7.3kW, 32A, 220V, OCPP1.6, Wall Mounted
Key Specifications / Features
Model no.: ACEVC-20240815-06
Hits: 3
As a leading manufacturer of AC EV fast chargers in China, we provide a cutting-edge solution designed for efficiency and reliability. Our charger features the OCPP 1.6 interface and delivers a robust 7.3kW output with a 32A input/output current. Built for durability, it boasts an IP54 rating, ensuring protection against dust and water. With a 220V input voltage and a generous 5-meter cable length, it offers flexibility and ease of installation. Ideal for both residential and commercial use, our fast charger combines advanced technology with practical design to meet your electric vehicle charging needs effectively.
Request a quote
Tags
Detail Information
AC Electric Car EV Charger, Single-phase, 7.3kW, 5M Cable, OCPP1.6, IP54.
| Product Item: | AC EV Fast Charger |
| Interface Standard: | OCPP1.6 |
| IP Degree: | IP54 |
| Output Current: | AC |
| Output Power: | 7.3kW |
| Input Voltage: | 220V±10% |
| Rated Intput Current: | 32A |
| Rated Output Voltage: | 230V±10% |
| Rated Output Current: | 32A |
| Charger Connector: | Type 2 |
| Way of Communication: | Bluetooth, Wi-Fi/Ethernet/4G Optional |
| Screen Size: | 4.3-inch Color Touch Screen |
| Length of Charging Plug: | 5M |
| Way of Installation: | Wall Mounted (Column Optional) |
| Size(H*W*D): | 170*400*110mm |
| Weight: | ≤3.7kg |
| Operating Temperature: | -30°C to +50°C |
| Storage Temperature: | -40°C to +70°C |
| Standby Power Consumption: | <5W |
| Electricity Measurement: | Build-in Metering Chip |
| Residual Current Protection: | 6mA DC RCD Internal |
| Multiple Protection: | With Over Voltage Protection, Under Voltage Protection, Overcurrent Protection, Grounding Protection, Surge Protection, Short Circuit Protection. |
