Fast EV Charger Station, 120kW, OCPP1.6, Ethernet/4G Optional
Key Specifications / Features
Model no.: DCEVC-20240815-03
Hits: 2
As a leading 120kW fast EV charger station manufacturer from China, we provide high-performance charging solutions tailored to meet the needs of modern electric vehicles. Our chargers deliver a powerful 120kW output and are equipped with the OCPP 1.6 interface for seamless network integration. With a 380V input and 200A output, they ensure efficient and rapid charging across a wide DC voltage range of 150-1000V. For flexible connectivity, we offer optional Ethernet and 4G communication modules. Our fast EV chargers are designed to meet the highest industry standards, offering reliability and innovation in every charge.
Request a quote
Tags
Detail Information
| Product Item: | 120kW Fast EV Charger Station |
| Interface Standard: | OCPP1.6 |
| Output Current: | AC |
| Output Power: | 120kW |
| Input Voltage: | 380V±10% |
| Rated Output Voltage: | 150-1000V DC |
| Output MaxCurrent of a Single Plug: | 200A |
| Output Constant Power: | 300-1000V DC |
| Rated Frequency: | 45-60Hz |
| Output Efficiency: | 96% |
| Screen Size: | 7-inch |
| Way of Communication: | Ethernet/4G Optional |
| Cable Length: | 5 Meters * 2 |
| IP Protection: | IP55 |
| Size(H*W*D): | 1800*730*514mm |
| Power Factor: | ≧0.99 |
| Operating Temperature: | -25°C to +55°C |
| Storage Temperature: | -35°C to +65°C |
